Touch switch module, 25mm penetration, 12-24V, 60W, dimmable
Dimmable touch switch for discreet lighting control, it is mounted hidden behind wooden, plastic or glass panels and operates by touch through materials up to 25 mm. A short press turns the light on or off, a long press adjusts the intensity between 10 and 100%. It operates at 12-24VDC, supports up to 5A 60W, ideal for LED strips and compact lighting fixtures.
Shipping by Thursday 27 August
International fast shipping within EU. Free Shipping for orders above 100 EUR in most EU countries.
We ship from our stock within 24H
You earn points with every order, worth 5%.
The FTS-02A dimmable LED touch switch is a modern and innovative solution for discreet and efficient lighting control. With an invisible design, this lighting switch preserves the aesthetics of various surfaces, while providing an intuitive experience by simply touching the surface.
The lights are activated by touch only, the switch remaining hidden, for impeccable aesthetics. A short press switches between ON and OFF, and a long press allows you to adjust the intensity (Dimmer) between 10 and 100%.
It has a maximum capacity of 5A/60W, at a voltage between 12 and 24VDC, being compatible with multiple types of lighting fixtures, from lamps and ceiling lights to LED strips.
It is mounted directly on wooden, plastic or glass panels, without the need for other equipment.
It operates on 12V and 24V voltages, adaptable to different lighting systems, and represents an elegant alternative to traditional switches.
Specifications:
Supply voltage: 12- 24VDC
Maximum load: 5A / 60W
Material: Plastic
Switch type: Touch On/Off
Detection range: ≤25 mm ( May vary )
Compatible material: Wood, Plastic, Glass
Model: FTS-02A
Dimensions: 48 x 48 x 6mm
Use:
Choose a wooden panel with a maximum thickness of 25 mm for mounting. Fix the switch behind the panel, in the desired control area.
Connect the switch to the power source (12V or 24V) respecting the voltage specifications of the lighting fixtures. The sensor has two groups of wires. The first set is for input, the second for output, marked IN and OUT. On IN will connect the power source between 12V and 24VDC, on the output will connect the lighting fixture or LED strip.
Once mounted, the switch can be used by simply touching the panel surface, activating or deactivating the lights.
A short touch switches between ON and OFF. A long touch allows dimming the light.
The dimmer comes with input and output jacks, marked with a label. The minus is marked with a DISCONTINUOUS WHITE LINE on both the supply and output.
