LoRa M5 Stack module with E220 transceiver, 433MHz, 5V
High-performance LoRa solution for long-distance wireless communications, ideal for IoT, remote sensors and monitoring. It operates at 433 MHz with coverage up to 10 km in open field, UART interface with AT commands for quick integration with Arduino and similar boards, adjustable 22 dBm emission power and ultra-low sleep consumption of up to 2 uA.
Shipping by Thursday 27 August
International fast shipping within EU. Free Shipping for orders above 100 EUR in most EU countries.
We ship from our stock within 24H
You earn points with every order, worth 5%.
The M5Stack module with LoRa E220 transceiver is a high-performance wireless communication solution, designed for projects that require long-distance transmissions. Operating at a frequency of 433 MHz, the module can provide communications up to 10 km in open field, making it ideal for IoT applications, remote sensors or monitoring systems. It is fully compatible with Arduino and other development boards, making it easy to integrate into various electronic projects.
The module supports multiple operating modes (Normal, WOR Transmit, WOR Receive and Configuration), providing flexibility depending on the application needs. Transmission is done via the UART interface, with a baud rate of up to 115200 and support for AT commands. Power consumption is optimized, with only 2 µA in sleep mode, which makes it suitable for battery-powered applications.
Specifications:
Supply voltage: 5V
Frequency: default 433 MHz (support 410.125 ~ 493.125 MHz)
Transmit power: 22 dBm (adjustable)
Reception sensitivity: up to -137 dBm
Interface: UART, baud rate 115200, AT commands
Working modes: Normal, WOR Transmit, WOR Receive, Configuration
Consumption:
- Transmission ≤ 120 mA
- Standby ≤ 2.5 mA
- Sleep ≤ 2 µA
Operating temperature: 0 ~ 40°C
Weight: 19.4 g
Antenna: 110 mm
Dimensions: 71.4 × 24 × 8 mm
HY2.0-4P cable: 20cm
Use:
Connect the module to the development board via the UART interface.
Attach the included antenna to ensure stable transmission.
Select the desired mode by configuring pins M0 and M1:
- Normal: M0 Off, M1 Off → data transmission and reception
- WOR Transmission: M0 On, M1 Off → wake-up over the air and data transmission
WOR Reception: M0 Off, M1 On → data reception only
Configuration: M0 On, M1 On → parameter setting via AT commands
Respect the maximum voltage of 5V to avoid damaging the module.
Working mode:
| Operating mode | Functionality | Pin configuration (M0 / M1) |
|---|---|---|
| Normal | Data transmission and reception | Off / Off |
| WOR Transmission | Supports wake-up over the air and data transmission | On / Off |
| WOR Reception | Data reception only (no transmission) | Off / On |
| Configuration | Allows parameter setting via AT commands | On / On |
The package contains:
M5Stack LoRa E220 Module
433MHz antenna
HY2.0-4P cable (20 cm)
