DC voltage booster module XL6009 with display, 5-35V, 4A
Efficiently boosts DC voltage to power equipment from a smaller source, adjustable between 5 and 35V and current up to 4A. Displays input or output voltage selectable via button, offers efficiency of up to 94 percent and low ripple for stable output, includes low power mode with display off on long press.
International fast shipping within EU. Free Shipping for orders above 100 EUR in most EU countries.
We ship from our stock within 24H
You earn points with every order, worth 5%.
DC-DC boost step-up source module, with display showing input and output voltage, selectable via button. This module efficiently boosts the input voltage to values between 5 and 52V.
Specifications:
Input voltage: 4.3 - 32VDC
Output voltage: 5 - 35VDC
Input current: 4A MAX, recommended below 4A (check temperature and ensure cooling at higher temperatures)
Standby current (no load): 18mA (increases with higher output voltage)
Conversion efficiency: <94%, higher efficiency at closer input and output values
Frequency: 400KHz
Output ripple: 50mV, increases with voltage rise
Voltage adjustment accuracy: ± 0.5%
Operating temperature: -40 ℃ ~ +85 ℃
Dimensions mm: 70 x 38mm
Button operation mode:
Long press: low power state, the display will turn off
Short press: display turns back on
- tension
- AD
- Supply Voltage
- 4
- Maximum Input Voltage
- 32
- Minimum Output Voltage
- 5
- Maximum Output Voltage
- 35
- Source Type
- high
- Current Adjustment
- Not
- Voltage Adjustment
- Yes
- Adjustment Type
- Variable
- Maximum Output Current
- 4
