Digital Voltmeter, 0.28'', 0-100VDC, 3 wires, Blue
Mini module for fast DC voltage monitoring, with 0.28 inch blue display and clear 3-character readout. Measures 0-100VDC, operates at 4-30VDC and uses 3-wire connection for simple installation with common ground. Low power consumption below 20mA, automatic decimal point and mounting lugs for stable mounting.
Shipping by Thursday 27 August
International fast shipping within EU. Free Shipping for orders above 100 EUR in most EU countries.
We ship from our stock within 24H
You earn points with every order, worth 5%.
Mini voltmeter module with 0.28 inch display, Blue color, which can display a voltage between 0 and 100VDC.
It is provided with 3 wires, two for power and the third for voltage measurement. Attention , the supply voltage is between 4 and 30 VDC . The supply is made through the Red and Black wires. The third wire (White or Yellow, depending on the batch) will be placed on the Cathode (+), which actually measures the voltage. To work, it is necessary that the circuit has a common GND.
The module has mounting ears. of 33mm.
The decimal point moves automatically.
Specifications:
Supply voltage: 4 - 30VDC
Measured voltage: 0 - 100VDC
Current consumption: <20mA
Display: 3 characters with a decimal point, digital tube
Display size: 0.28 inch
Display color: Blue
Refresh rate: 200ms
Accuracy: +-1% declared. From the tests, at low voltages there is a gap of up to 0.4V.
Operating temperature: -10 - 65 degrees C
Dimensions mm: 33 x 10.7 x 7.5mm (ears included)
Wire length: 10cm approximately
Number of threads: 3
