Digital balance charger, B6 V3, 80W, Lipo, Li-Ion, LiHv, NiMh, NiCd

Professional B6 battery charger, 80W, V2 version with blue case, with balance port, discharge function, and battery storage mode.

It features a temperature sensor input, microprocessor control, and automatic cell count detection. It also supports LiHV batteries, which have a charging voltage of 4.35V per cell, as well as Smart Batteries I, II, and III (cable not included).

Among its main features are automatic cell count detection, a lithium cell internal resistance test function, support for LiHV and Smart Battery I, II, and III (cables not included for these batteries). It includes safety functions such as minimum input voltage setting, battery capacity, maximum charging time, and temperature protection. It allows charging voltage adjustment, individual cell balancing, and saving settings in 20 memory slots. It offers cycle charge/discharge, Fast Charge, and battery discharge.

The battery storage function (Storage Mode) discharges the cells to the nominal voltage of 3.85V for long-term storage. In addition, the output voltage is adjustable, so the device can also be used as a stabilized power supply, with the option to set the desired voltage.

Choose the correct battery type and cell count when charging! Ignoring proper cell charging practices can cause fire! DO NOT charge lithium batteries without connecting the balance port!

Specifications:

Supply voltage: 11 - 18VDC

Charging current: 0.1 - 6.0A

Maximum power: 80W

Discharge: Max 5W, internal

Balance current: 200mA

Compatible batteries 1-6S: LiPo, LiHV, LiIon, LiFe

Compatible batteries 1-15S: NiCd, NiMh

Compatible lead-acid batteries: 2 - 20VDC

Display: LCD1602 display

Functions:

- Automatic cell count detection

- Lithium cell internal resistance test function

- LiHV support

- Smart Battery I, II, III support (cables not included for these batteries)

- Safety functions: minimum input voltage setting, battery capacity, maximum charging time, temperature protection

- Charging voltage adjustment

- Individual cell balancing

- Memory function, 20 slots

- Cycle charge/discharge

- Fast Charge

- Battery discharge

- Battery storage function (Storage Mode). Cells are discharged to the nominal voltage of 3.85V for long-term storage

- Adjustable output voltage: can be used as a stabilized power supply, with the option to set the output voltage

Contents:

1 x B6 V2 charger

1 x 220VAC power adapter

1 x Wire set

*The photos above show the V3 version (black case), but the functions and usage are identical.

⚠️ WARNING – RISK OF ELECTRIC SHOCK

This product uses a power supply operating at 100-240 VAC. Assembly, connection, and any intervention on the input terminals must be carried out EXCLUSIVELY with the electrical installation disconnected from the mains. Connections to the 220V mains must be performed only by authorized personnel, in accordance with the applicable electrical regulations.
