Rail-mounted power supply module, 100–240 VAC to 24 VDC, 15 W
DIN rail power supply module for electrical panels, converts 100-240VAC to regulated 24VDC for automation, sensors, and control circuits. It provides 15W and up to 0.63A, has a compact 17.5mm housing, and passive fanless cooling for silent operation. It includes overload and overvoltage protection, with protected screw terminals for safe installation.
Shipping by Thursday 27 August
International fast shipping within EU. Free Shipping for orders above 100 EUR in most EU countries.
We ship from our stock within 24H
You earn points with every order, worth 5%.
The HDR-15-24 power supply is a compact AC-DC converter, designed for mounting on a standard DIN rail in electrical panels. It delivers a stabilized 24 VDC output at a maximum current of 0.63A, with a power rating of 15W, from an input voltage range of 100 - 240 VAC, making it compatible with power grids worldwide without any modification.
The fanless construction ensures silent and reliable operation, with passive cooling through the aluminum housing. The slim 17.5mm width (1SU) allows multiple units to be mounted side by side on the DIN rail without taking up additional space. The covered screw terminals are protected against direct contact, meeting safety requirements for industrial installations.
The power supply includes built-in overload and overvoltage protection. The output voltage is stabilized with a maximum variation of ±0.5% for input voltage changes and ±2% for load changes.
Specifications:
Model: HDR-15-24
AC input voltage: 100 - 240V AC, 47 - 63Hz
Output voltage: 24 VDC ±2%
Output current: 0 - 0.63A
Maximum output power: 15W
Ripple and noise: 150mV max (pk-pk)
Line regulation: ±0.5%
Load regulation: ±2%
Typical efficiency: 86%
Hold-up time: 12ms at 115 VAC / 30 ms at 230 VAC
Start-up time: 2000ms
Protections: overload, overvoltage
Operating temperature: -30 ~ 70°C
Humidity: 20 ~ 90% RH (non-condensing)
Mounting type: standard DIN rail
Width: 17.5mm (1SU)
Dimensions: 90 x 17.5 x 54.5mm
Use
Mount the power supply on the DIN rail. Make sure the panel is disconnected from the mains before making any connections. Connect the phase wire to terminal L and the neutral wire to terminal N. Connect the load between Output + and Output - terminals, observing polarity.
After connecting to the mains, check the output voltage with a multimeter.
Dimensions diagram:
⚠️ WARNING – ELECTRIC SHOCK HAZARD
This product operates at 100-240 VAC. Installation, connection, and any work on the input terminals must be performed ONLY with the electrical system disconnected from the mains. Connections to the 220V mains must be carried out only by authorized personnel, in accordance with the applicable electrical regulations.
